Brand Name: --
Model Number: C12200
Place of Origin: Shandong, China (Mainland)
Type: Straight Copper Pipe
Application: Water Tube
Specification: Required
Outer Diameter: 1.83-305mm
Grade: Cooper
Thickness: 0.35-7mm
Length: 3-12M
Cu (Min): 99.9%
Alloy Or Not: Non-alloy
Ultimate Strength (≥ MPa): 245
Elongation (≥ %): 40%
Wall Thickness: 0.35-7mm
Outside Diameter: 1.83-305mm
Keyword: straight copper pipe
Usage: hot and cold water
PriceTemrs: FOB or CFR or CIF
Port: Qingdao / Tianjin or as customer're requirement
Material: Copper C1220
Packing: Each end capped then wrapped with plastic bag then in wooden box
Shape: straight
Hardness: hard, half hard, soft
Standard: ASTM B280 B68 B75 B88 B837 AND EN1057
Delivery Time: 15-20 days after deposit
Large diameter air conditioner straight copper pipe
Chemical and mechanical property
Copper Alloy No. |
Chemical Composition
|
Temper |
Mechanical Properties |
|||
Tensile strength (Mpa) |
Elongation (%) |
Grain Size (mm) |
||||
CU% |
P% |
|||||
C12200 |
99.9 |
0.015-0.040 |
H58 |
≥ 250 |
||
O50 |
≥ 205 |
0.025 |
||||
O60 |
≥ 205 |
0.040 |
straight copper pipe
copper plumbing tube
copper pipe
1. Top class quality
2. Competitive price
3. Low MOQ reuirement
4. Quick response
6. Free samples can be provided (under 1KG)
