Waterproofing PE Foam Sheet with Self adhesive

Waterproofing PE Foam Sheet with Self adhesive

FOB Price:

US 0.8-3.5 / Square Meter

Min.Order Quantity:

1000 Square

Supply Ability:

5000 Square per Meter/Square

Port:

Guangzhou/Shenzhen

Place of Origin:

Guangdong, China (Mainland)

Payment Terms:

L/C,D/A,D/P,T/T,Western Union,MoneyGram,PAYPAL

Brand:

Products Model:

HI-PE

Products Details
Company Profile

Quick Details

Brand Name: CF

Model Number: HI-PE

Place of Origin: Guangdong, China (Mainland)
Type: Other Heat Insulation Materials
Shape&Structure: Closed cell structure
Density: 28-35kg/m3
Thickness: 3mm-50mm
width: 1m or 1.2m
Characteristics: Flame Retardent
Application: AirDuct Insulation
Surface: plain
Material: PE
Color: grey

Packaging & Delivery

Packaging Details: 1 Roll Per Polybag/PE Bag or Paper Carton
Delivery Detail: 10 Working Days After Order Confirmation

Specifications

Product Description

HVAC PE Thermal Insulation Foam Description

PE Foam Insulation Description:

PE Foam Sheet which is known as Polyethylene Foam is a firm and closed cell foam with cross-linkage that provide more rigidity. PE Foam Sheet is very hard to recover to original shape after compression and doesn't spread compressed energy easily. Due to heat-absorbing and shock-absorbing properties, this closed cell foam is great to weaken the effect of vibration. Ideally suited as packaging material for long-distance transportation.

Polyethylene (PE) foam, full closed cell structure, is made from LDPE, flame retardants, etc., and free from PVC, gives out low smoke and non-toxic matter.

CF PE Insulation Foam Characteristics:

• Excellent shock and vibration absorption

• High buoyancy with less tendency for water absorption

• Eco-friendly, accord with environmental protection requirement

• Shatter-proof, superior resistance against grease and chemical corrosion

• Good thermal insulator and well touch feeling over a wide range of weather temperature

Advantages:

• Good strength with tear resistance

• Non-dusting, non-toxic and no peculiar smell

• Available in single sided or double sided adhesive

• Superior resistance to moisture, mildew and mould

Our PE insulation foam are in strict accordance with international standards to produce, to ensure its quality.On the waterabsorption in vacuum performance,it reaches 0.0019g/cm3. Please see the table below!

Item		Unit	Testing Standard	Parameters
Surface Density		Kg/m³	GB/T6343-1995	28-45
Burning Grade		——	GB8624-1997	B1
Burning Performance	Oxygen Exponent	%	GB8624-1997	32.8
	Smoke Density	%	GB8624-1997	50
Heating Conductivity coefficient	Average Temperature 10℃	W/(m·k)	GB3399-1988	0.0327
	-20℃			——
	0℃
	40℃
Moisture Penetration	Coefficient	G/(m·s·pa)	GB/T 17794-1999	≤2.4×10^-10
	Moisture Resistance	——	GB/T 17794-1999	8.1×10²
Water Absorption in Vacuum		g/cm³	GB/T 1034-86	0.0019
Dimension Stability		%	GB/T8811-1988	0.66
70℃ ±3℃,48h
Rebound Rate after Compression		%	Q/(GZ) HD1-2003	96
Ripping Intension		N/cm	GB/T 10808-1989	3.3
Ozone endurance Ozone Suppressor202mPa,200h		——	GB/T 17794-1999	No Chaps
Aging Resistance(150h)		——	GB/T 17794-1999	No Wrinkle
				No Crack
				No Pinhole
				No Distort
Temperature Range		℃	-50~+90

We have many kinds of specifications for you to choose.The PE heat insulation foam width can be 1m & 1.2m, its thickness ranges from 3mm to 50mm. In order to facilitate the packing and transportation, its length varies with the thickness. Please see the table below!

Closed cell heat resistant insulation sheet sizes (pieces per carton box or polybag)

Wall (Thickness)	1/8” (3mm)	1/4" (6mm)	3/8" (9mm)	1/2" (13mm)	5/8”(16mm)	3/4” (19mm)	1” (25mm)	1 1/4” (32mm)	1 1/2” (38mm)	2” (50mm)
Width	1.0 or 1.2m
Length	2.0m or 1.2m
pcs/ctn(bag)	80	40	26	20	16	14	10	8	7	5

Closed cell heat resistant insulation roll sizes

Wall (Thickness)

1/8” (3mm)

1/4" (6mm)

3/8" (9mm)

1/2" (13mm)

5/8”(16mm)

3/4”

(19mm)

1”

(25mm)

1 1/4”

(32mm)

1 1/2”

(38mm)

2”

(50mm)

Width

0.5m, 3feet, 1.0m, 1.2m, 4feet or 1.5m

Length/ctn(bag)

30m

20m

10m

Guangzhou Cheerfore Insulation Co., Ltd. endeavors in R&D and innovation of thermal insulation, acoustic insulation, vibration absorption and sealing materials since its foundation in 2006. We concentrate on thermal insulation products for power equipments and mechanical facilities, HVAC&R and construction works, etc, and acoustic and vibration insulation products for meeting room, anechoic room, industrial buildings, automobile industry, etc, and the relative accessories which to ensure the insulations work properly and efficiently.
